IPD-3634IQ-28Z-SWA

4MP Intelligent StarLight Dome, (VF. 2.8-12mm) mic. 50m IR, 30m FLED

Direct link to this product's page

— 1/1.8" CMOS Image Sensor, max. 2688×1520@30fps
— Motorized lens: 2.8-12mm/F1.2, Angle of View (H): 49.2° ~102.4°
— Colour: 0.0005 Lux, 0 Lux with IR
— Built in White LEDs and IR light, up to 50m range
— 120dB True WDR, 2D/3D DNR
— Main stream: 4MP (2688x1520), max. 30fps Sub Stream: 720P (1280x720), max. 30fps Third Stream: D1 (720x576), max. 30fps
— Triple Video Streaming, (ONVIF + API Compatible Integration )
— Built in Microphone
— VCA Alarm Light with White LED
— Two-way audio, Alarm I/O
— Motion Detection-4 areas, Privacy Mask-4 areas
— Smart: Intelligent perimeter protection, include cross line, intrusion, enter area, leave area detection
Based on target classification, smart intrusion prevention significantly reduce false alarm caused by leaves, birds and lights etc., accurately focus on human and, motor vehicle and non-motor vehicle
— 9:16 Corridor format, Up to 8 OSDs
— MicroSD card (up to 512 GB)
— Power: DC12V ±25%//PoE (802.3af) Max 10W , 6KV surge protection
— Working Environment -30°C~+60°C, Ingress Protection IP67
— Size: Φ129x110 mm - 0.66 kg

— Compatible Junction Box: TR-JB03-H-IN
— Compatible Wall Bracket: TR-WM03-B-IN
